LED Wall Pack, up to 55 selectable (35/45/55 watt) or 115 watt fixed.

This product family can be effectively used in outdoor wall mount locations in commercial, industrial, retail and institutional exterior lighting (i.e., parking lot, cargo door, high wall, area, security, etc).

Manufacturer: TCP

SKU: TWPUZD

Vendor: TCP

Select wattage: *

Selectable 35/45/55 watt
115 watt

Add Photocell if needed: *

No thanks
Add Photocell

$92.00

PRICE BREAKS - The more you buy, the more you save

Quantity

14+

Price (for lowest priced product of this type)

$89.00

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Overview

LED Wall Pack by TCP.

Reasons to choose the LED Wall Pack from TCP:

Energy efficient – Uses less energy than traditional fixtures, resulting in instant energy savings
Long 50,000 hour rated life minimizes replacements and reduces overall labor costs throughout the life of the fixture
UL approved for wet locations
Durable die-cast aluminum housing with impactresistant polycarbonate lens protects the LED in harsh environments

Ideal Applications:

Site Lighting
Security Lighting
Entrances
Perimeters

See PDF for more info

Input Line Voltage............................ 120V-277V, 120V-347V
Input Line Frequency (Hz)......................................50/60HZ
Wattage(W).............35/45/55W Selectable & 115W Fixed
Lumens(L).......4725/6075/7425L Selectable & 15525L Fixed
Lumens per Watt (LPW)...........................................135LPW
CCT............................................. 2950K, 4000K, 5000K
Rated Life......................................................50,000 hours
Minimum Starting Temperature...........................-40°C (-40°F)
Maximum Operating Temperature......................50°C (122°F)
CRI...........................................................................>80
Power Factor...........................................................>0.95
THD........................................................................<20%
Surge Protection.................................... 4KV (Line to Ground)
Ratings........................................... cULus wet location rated
Controls........... 0-10V Dimming (standard), PC option available

LED Wall Pack by TCP.

Reasons to choose the LED Wall Pack from TCP:

Energy efficient – Uses less energy than traditional fixtures, resulting in instant energy savings
Long 50,000 hour rated life minimizes replacements and reduces overall labor costs throughout the life of the fixture
UL approved for wet locations
Durable die-cast aluminum housing with impactresistant polycarbonate lens protects the LED in harsh environments

Ideal Applications:

Site Lighting
Security Lighting
Entrances
Perimeters

See PDF for more info
